Product Highlights

• Maximum length of Boom: 6 meters
• Boom Rest Stand: Yes (available)
• Arm Material: Aluminium
• Opening Time for Up/Down: 6s<

Technical Specifications

• ✔ Maximum length of Boom: 6m
• ✔ Boom Rest Stand: Yes
• ✔ Arm Material: Aluminium
• ✔ Opening Time for Up/Down: 6s
• ✔ Input Control Signal: Dry Contact
• ✔ Ingress Protection Degree: IP54
• ✔ Input Interface for:
• ✔ Photocell
• ✔ Air Switch
• ✔ Loop Detector
• ✔ Output Interface: Lamp
• ✔ Optional Interface:
• ✔ Access Control Panel
• ✔ Standalone Access Control
• ✔ Control Button
• ✔ Remote Control: Yes, up to 25 meters
• ✔ Mode: Automatic / Manual
• ✔ Incorporated Control Panel with 3 Push Buttons (STOP / UP / Down) to Control the Motor
• ✔ Bumping Bounce Back: Optional
• ✔ Auto Closing Time: 1–80s

Power Supply

• ✔ SMPS - Input: AC 220V / 110V, 50Hz / 60Hz
• ✔ Motor Power: 90W, 220V AC
• ✔ Dimension (mm): 268 x 348 x 1050
• ✔ Operating Temperature: -20°C to +50°C

Features

• ✔ Can be controlled by three-position switch or remote control unit (OPEN, CLOSE, STOP)
• ✔ Machine core with compression spring to prevent accidents from spring breakage
• ✔ Motor cooling fan to solve heat protection issues
• ✔ Double safety limit switches (Optional)
• ✔ Auto Close Function
• ✔ Manual Release
• ✔ Duty Cycle: 100%
• ✔ Supports external and internal Loop Detector (Optional)
• ✔ Traffic Light Interface (Optional)
• ✔ Wire Control (Switch Signal) / Remote Control (up to 25m)
• ✔ Compatible with Wiegand and RFID Readers
• ✔ Compatible with Biometric Systems
• ✔ Die-cast Aluminum Alloy Motor – durable and thermally efficient
• ✔ Supports Infrared Photocell for Anti-Bumping Function (Optional)
